Dayliff DSD 3/18 Submersible Borehole Pump Kenya

The Dayliff DSD 3/18 price in Kenya is KSh 33,000 without a float switch or KSh 36,000 with a float switch. This 1.5 HP submersible multistage centrifugal pump is designed for domestic and small-scale water supply from wells and boreholes. With a maximum head of up to 129 metres, it suits water systems that require greater pumping head.

Dayliff DSD 3/18 Specifications

The Dayliff DSD 3/18 specifications make it suitable for deeper borehole applications and domestic water systems that require higher pressure.

The pump uses stainless-steel housing, shaft and coupling, together with cast-iron suction and delivery chambers. In addition, its polycarbonate impellers and diffusers provide suitable performance for water containing limited sand.

Dayliff DSD 3/18 Borehole Pump Applications

The DSD 3/18 can supply water from boreholes and wells to homes, storage tanks and other small water systems. Its higher head also makes it suitable for installations where the water must travel a significant vertical distance.

Common applications include:

• Domestic borehole water supply
• Deep-well water pumping
• Water tank filling
• Household water distribution
• Small-scale irrigation
• Residential and small commercial water systems

For more options, explore submersible water pumps in Kenya.

Dayliff DSD 3/18 With or Without Float Switch

Pureflex offers the DSD 3/18 in two configurations. The version with a float switch provides an additional water-level control option. Meanwhile, the version without a float switch suits installations that already have a suitable control system.

Both configurations use the same 1.5 HP DSD 3/18 pump. Therefore, the main difference is the included float-switch setup.

The DSD range also comes with a 30m cable and control box for the relevant models.

Why Choose the Dayliff DSD 3/18?

The DSD 3/18 combines a 1.5 HP motor with 18-stage multistage pumping. As a result, it can provide the higher head required by some deeper borehole and elevated-tank installations.

However, maximum head does not mean the pump will deliver its maximum flow at that height. Actual performance changes according to the operating point.

Therefore, check the borehole water level, vertical lift, pipe length, pipe diameter and required flow before choosing the pump.

Is the Dayliff DSD 3/18 Suitable for Your Borehole?

A pump’s horsepower alone cannot determine whether it will work for a specific borehole. First, check the borehole diameter and static water level. Next, determine the height from the water level to the delivery point. Finally, consider pipe losses and the required water flow.

The DSD 3/18 is designed for a minimum borehole diameter of around 110mm. Its submersible design allows installation inside suitable wells and boreholes.

For a more accurate selection, calculate the total dynamic head rather than using borehole depth alone. This calculation gives a better indication of the pump’s actual operating requirements.

Buy Dayliff DSD 3/18 in Kenya

The Dayliff DSD 3/18 provides a 1.5 HP solution for domestic and small-scale borehole water supply. Its multistage design and high maximum head make it suitable for water systems that require substantial pumping lift.

Before ordering, provide the borehole depth, static water level, distance to the tank, elevation and required flow rate. These details help determine whether the DSD 3/18 matches the installation.
